IP65 784 STROBE ELECTRIC BAR STAGE LIGHT

Light Source672 pcs*0.5w RGB 5050 0.2W LEDs+112 pcs*3W SMD 3535 LEDs
LED Life Expectancy50,000 hours
Beam Angle160°
Protection RateIP65
Product Dimension1006x129x153mm
Net Weight 7 kgs (15.4 lbs)



Edit Content
2 6

Overview

IP65 high-performance 784 Strobe Electric Focus is an outdoor LED bar light for stage, featuring 672 pcs*0.5w RGB 5050 0.2W LEDs+112 pcs*3W SMD 3535 LEDs,it is an impressive LED led bar with super light weight design and electronically controlled frost.

This powerful led bar strobe light is a specialized stage light or decorative lighting fixture,featuring 32 RGB-zones+16 CW-zones controlled, designed to create dynamic visual effects and patterns.

It’s capable of smooth, wide washes or tight, defined light—all from the same bar. Enhanced color accuracy, DMX control, and advanced pixel grouping make it a professional-grade fixture built for designers who crave precision, power, and flexibility.

IP65 Protection rate, is suitable for indoor&outdoor stage applications.



Technical & Specification



Model

Model Name: 784 Strobe Electric Focus Bar
Model Code: LB-784IP



Light Source

Light Source: 672 pcs*0.5w RGB 5050 0.2W LEDs+112 pcs*3W SMD 3535 LEDs
Life Expectancy: 50,000 hours



Optical System

Beam Angle: 160°



Control

4 touch button control panel
Display: OLED display
Protocols: DMX512,sound activated or auto operation
Control Channels: 16/4/6/24/30
Firmware Upgrade: Upgrade via DMX link



Other Effects

Outstanding strobe effect with variable speed
Flicker-free management
Dimmer: 0~100%
Horse race effect
Individual LED zones: 32 RGB-zones+16 CW-zones
Pulse effect
Strobe:1-30Hz
Pure smooth Color Mixing
Smooth Dimmer: 0~100%
Electric frost with variable speed
Different kinds of preset macro effects with variable speed
Outstanding strobe effect with variable speed
Splicing surfaces,capable for assembling any shape







Electrical and Connectors

Input Voltage Range: 90-260V AC,50/60Hz
Power Consumption : 450W
Power In/Out: IP65 power connector IN/OUT
Data In/Out: IP65 3-pin XLR connector IN/OUT



Housing

Material: Aluminum die-cast
Finishing:Matt black
IP Rate: IP65
Net Weight: 7 kgs(15.4 lbs)
Gross Weight: 8.5 kgs (18.7 lbs)



Cooling System

Advanced cooling system integrated aluminum
Constant temperature readout and management function
Over temperature protection management



Work Environment

Maximum Ambient Temperature: 40°C
Minimum Operating Temperature: -10°C
Protection Rating: IP65



Approvals

CE compliant
RoHS compliant



LB 784 1 pdf



1 4







Optional Accessories



信号线



NAME: 3-PIN XLR Signal Cable
ORDER CODE:3-PIN Signal cable

电源线



NAME: PowerCon Cable
ORDER CODE : PowerCon Cable

灯钩jpg 1



NAME: Clamp
ORDER CODE : Bclamp,Mclamp,Sclamp

安全绳

NAME: Black Safety Chain
ORDER CODE : Bchain

omega

NAME: Omega Blacket
ORDER CODE :Lomega,Momega,Somega

flight case

NAME: 2 IN 1 FLIGHT CASE
ORDER CODE : 2IN1 FC
