Overview

IP20 40x3W Led Bar Light is an indoor LED effect light, featuring RGBW LEDs,it is an impressive LED bar light with super light weight design.

This latest stage light is a specialized stage or decorative lighting fixture,featuring each pixel controlled,designed to create dynamic visual effects and patterns,often used for backdrops,events,and architectural lighting.Key features include full RGBW color mixing,multiple control modes,energy efficiency,and flexible installation options,making them versatile for various entertainment and decorative purposes.

IP20 Protection rate, is suitable for indoor applications.

Technical & Specification

Model

Model Name: IP20 40X3W LED BAR
Model Code:LB-4003

Light Source

Light Source: 40X3W RGBW LEDs
Life Expectancy: 50,000 hours

Optical System

Beam Angle: 8°

Control

4 touch button control panel
Display: OLED display
Protocols: DMX512,sound activated or auto operation
Control Channels: 3/4/6/7/8/12/13/24/25/60/61/120/121

Other Effects

Outstanding strobe effect with variable speed
Smooth dimming 0-100%
Flicker-free management
Pulse effect
Strobe:1-30Hz
Pure smooth Color Mixing
Different kinds of preset macro effects with variable speed
Each pixel controlled
Dual mounted bracket design

Electrical and Connectors

Input Voltage Range: 90-260V AC,50/60Hz
Power Consumption : 100W
Power In/Out: IP20 power connector IN/OUT
Data In/Out: IP20 3-pin XLR connector IN/OUT

Housing

Material: Metal+ABS Plastic
Finishing:Matt black
IP Rate: IP20
Net Weight: 3 kgs(6.6 lbs)
Gross Weight:3.8 kgs (8.3 lbs)

Cooling System

Advanced cooling system integrated aluminum
Constant temperature readout and management function
Over temperature protection management

Work Environment

Maximum Ambient Temperature: 45°C
Minimum Operating Temperature: -10°C
Protection Rating: IP20

Approvals

CE compliant
RoHS compliant
